New Release: Eachine EV900 HD FPV Goggles First Look/Review

Eachine have just announced a new set of full HD (1920 x 1080) FPV goggles, the Eachine EV900. These goggles follow closely after the popular EV100, which I looked at previously.

The EV900 have an incredible feature set, and for anyone looking for a full HD headset, these are a fantastic choice. There are however a couple of things that let these goggles down. Read on to find out what they are, as you may be able to live with them!

With lots of new goggles being released into the market, it can be hard to decide which ones to go for. In choosing, remember that a good pair of goggles can really enhance your FPV experience. Have a look at the features and make sure that everything you want is covered. For most people this includes: digital input, defogging fan, DVR, reasonable FOV and resolution. Remember to pair your goggles with a good camera, like the Runcam Swift 2, if you want to make the most of them. Using a low quality camera with good goggles is not a good use of your money.

Eachine EV900 release date

The Eachine EV900 release date is currently unknown, but you can check here for updates. Make sure you check back for an update once we have more details.

Eachine EV900 Specifications

The EV900 have an impressive specification, with features like:

  • 1920 x 1080 resolution
  • Large 85° FOV
  • Mini HDMI or analogue input
  • Diversity receiver built in with autoscan feature
  • Built in battery with 2h 10m run time
  • Can be powered via USB/Powerbank to extend battery life
  • High brightness screen

Eachine EV900 Review – Cons

  • No DVR, which is disappointing. This is something that should be standard by now. Luckily, you can add an external DVR via the analogue output, so it is possible to record your flights.
  • Fit of faceplate is not good, and can cause light leakage. This is compensated for with the high screen brightness, but may still cause you trouble if flying in direct sunlight.

Eachine EV900 Review – Pros

  • Compact for a box goggle
  • Large clear image – no blurry images despite the huge field of view and resolution
  • 1080P screen – fantastic for PC simulator use or HD FPV systems – plug straight in with the included HDMI cable
  • Good digital smoothing when using an analogue signal
  • Comfortable face plate material
  • Diversity receiver with included omnidirectional and directional antennas ensures clear reception

Eachine EV900 price

The Eachine EV900 price is currently unknown, but you can check here for updates. It is expected that they will retail for $150-200

Full Eachine EV900 technical specifications below:



Compatible with multi devices via converting cables

Mini HDMI port:
iPhone  : lighting to HDMI, need power( Power adapter or power bank 5V) video: become slightly lower resolution, audio: Okay;
iPad : lighting to HDMI, need power( Power adapter or power bank 5V) video: become slightly lower resolution, audio: Okay;
MacBook : USB type-C to HDMI
MacBook Air, MacBook Pro  :  mini DP to HDMI
TV : HDMI to mini HDMI cable
Laptop with HDMI : HDMI to mini HDMI cable
Laptop or PC with VGA, no HDMI : VGA to HDMI

V-in port (in this port, we have Video in / Video out / Audio functions)
Other RX devices   :  Video cable
Cameras with analog video/ CVBS signal  : Video cable
TV : Video cable
Video out : When EV900 work on RX mode, analog video can be connect to a DVR recording device through this port.

Specification
Brand name Eachine
Item No. EV900
Item Name. EV900 hybrid HDMI AR VR FPV immersive racing goggles 5 inch 1920*1080 built-in Battery

Screen size: 5.0 inch
Screen resolution: 1920*1080 (No blur after enlarge by the lens)
Screen brightness: 600cd/m2 with special high brightness backlight LED for outdoor FPV
Refresh Rate: 120Hz, offer better, sharp, colorful screen view
View Angle: 140/120 degree(Horizontal/Vertical)
FOV 85 degree, immersive larger screen
Greatlines Tech
To make analog video with much more resolution TV lines. 3D noise reduction, Color enhancement…
DeepFeedback Tech
Real voice audio technology, to bring in great audio enjoyment
Lens
3x boost of the video to acquire intense feel-in-there video;
92% transparent rate no distort of light;
New lens is NOT a Fresnel lens anymore;
New lens support 1080P
Battery and recharge
Built-in 3.8V/2400mAh battery;
Each battery circle offer around 2hr10min working time;
5-18V wide recharging voltage range, typical recharging voltage is 5V
Accepts 5V power banks or 2S(7.4V)/3S(11.1V) battery as back-up power to have long working time
Receiver Build in 5.8G 40CH Raceband receive, ENHANCED with Greatlines technology

HDMI / V-IN(Audio) / 2.5DC power charging port
Body
Dimension: 148x 146 x 120 mm
Weight: 330g with 2hr10min 3.8V 2400mAh battery
Belt: three-ways adjustable belt
Features
– 5 inch 1920*1080px HD high brightness 120Hz refresh rate screen
– With Greatlines technology DSP chipset, offer low delay (latency 20-50ms) and HD video wirelessly;
– With DeepFeedback technology audio enhance AP, deliver great audio enjoyment.
– Multi-use port can be used to work with many other devices*, more than FPV;
– New designed, HD optic system, support 1080P, and no blur;
– With comfortable face sponge and AV IN/Audio OUT function;
– HD high brightness 5inch LCD specially tuned for FPV racing;
– Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
– Come with advanced auto-searching function ad show you the working frequency on screen;
– Built-in 3.8V/2400mAh battery, each full charge revive around 2hours 10mins working time;
– Wide range re-charge voltage 5-18V, power banks or 2S/3S batteries can be used as back-up power sour, to prolong the working time;
– Ergonomic design fit your faces;
– Super-wide visible angle up to 85 degree;
– 92% transparent lens adopted, no distort, no blur on the adage of screen;
– Light weight 330g with 2hr10min 2400mAh battery, RTF for any scale racing game.

Package Included
1 X EV900 AR VR FPV Goggles (Built-in 3.8V/2400mAh battery)
1 X StingPad Antenna
1 X K-loverleaves Antenna
1 X USB charger cable
1 X Battery charger cable
1 X AV IN cable
1 X User Manual
