New Release: Eachine EV200D FPV Goggles First Look/Review

Eachine have just released a second pair of budget FPV goggles, the Eachine EV200D. These goggles follow closely after the popular EV100, which I looked at previously.

The EV200D have a number of exciting features and it looks like Eachine may have a real contender for anyone looking for a Fatshark alternative.

With lots of new goggles being released into the market, it can be hard to decide which ones to go for. In choosing, remember that a good pair of goggles can really enhance your FPV experience. Have a look at the features and make sure that everything you want is covered. For most people this includes: digital input, defogging fan, DVR, reasonable FOV and resolution. Remember to pair your goggles with a good camera, like the Runcam Swift 2, if you want to make the most of them. Using a low quality camera with good goggles is not a good use of your money.

Eachine EV200D release date

The Eachine EV200D release date is currently unknown, but you can sign up here for updates. Make sure you check back for an update once we have more details.

The page currently states that the goggles will go on sale shortly after being reviewed by experienced users.

Eachine EV200D Specifications

The EV200D have an impressive specification, with features like:

  • 1280×720 resolution
  • Large 42° FOV
  • HD input
  • Built in DVR
  • True diversity
  • IPD adjustment
  • Can be powered via USB/Powerbank
  • Switchable aspect ratio 16:9/4:3



Full Eachine EV200D technical specifications below:

Eachine EV200D 1280*720 5.8G 72CH True Diversity FPV Goggles HD Port in 2D/3D Built-in DVR

Specification:
Brand Name : Eachine
Item Name : EV200D
Frequency : 5.8GHZ
Debug frequency: 5300MHz
Frequency range: 5333-5945MHz
Receiver Sensitivity : ≤ -93dB
Antenna Impedance : 50Ω
Audio and video: AV in/out
Video Format : NTSC/PAL
Brightness: adjustable
Contrast: adjustable
Pupil Distance adjusting: 56-72mm
Power input: 7.4v
Minimum voltage: 6.8v
Operating temperature: -10°C-40°C

Features:
FOV 42°
Built-in DVR
USB power supply
Resolution 1280*720
7.4V battery with LED indicator
Aspect ratio 16:9/4:3,Default display is 16:9
Supported display mode: HD Port in 2D/3D; AV in 2D/3D
IPD adjustable 56mm-72mm: Adjustable,wide-ranging IPD,suits more pilots
Optional diopter lens,compatible with Fatshark diopter lens,200/400/600 degrees selectable(diopter lens not include)
Dual true diversity,supports open source RX modules;compatible with Fatshark OLED RX modules

Package included:
1 x EV200D goggles
1 x 7.4v 1800mAh Battery
1 x USB Cable
1 x HD Port Conventor
1 x HD Port Cable
1 x 3.5mm AV Cable (one-in-three)
1 x Lens wiping cloth

Eachine EV200D FPV GogglesEachine EV200D FPV GogglesEachine EV200D FPV GogglesEachine EV200D FPV Goggles
